a |
constant effort supports
|
the comet range has been designed to give the optimum performance, occupying minimum space.
features include:
±20% site load adjustment.
travel indicator to allow movement to be monitored.
lever rotation indicator, to demonstrate at a glance that the support is taking load correctly.
low hysteresis, to ensure minimum load deviation.
infinitely variable locking/balancing device.
variable position load pin carrier.
construction that allows assembly after galvanising, without welding.
|
|
|
b |
variable effort supports
|
features of the comet range include:
wide load and movement range.
robust and compact design: installed heights designed to a minimum.
infinitely variable preset and locking device.
large stocks of semi-finished units held for quick deliveries.
|
c |
pipe clamps and ancillary equipment
|
a fully comprehensive range of pipe-supporting ancillary items for suspending or supporting pipework.
large quantities of these products are held in stock.
|
|
the comet range of dynamic restraints includes rigid struts, stiff clamps, fixing brackets and snubbers.
the comet snubber is one of the most sophisticated snubbers available.
features include:
variable lock-up rate, identical in both directions of movement.
thermal bleed facility to allow controlled creep after lock up.
sophisticated seal design.
internal reservoir to prolong service and recharging periods.
|
|
our fabrication expertise enables us to supply any necessary secondary support steelwork.
comet easi-slide bearings minimise frictional forces between pipework and supporting elements.
as well as the standard range shown in our catalogue, we supply special designs from glass-filled and bronze-filled ptfe to cater for high temperatures and/or high loads.
|
g |
comlin isolation products
|
available in a range of hardnesses, these products are used when strength and economy is provided by carbon steel components; but dissimilar metal corrosion, crushing, abrasion, vibration and noise are avoided by an intermediate barrier of comlin.
|
|
|
h |
isocast load-bearing insulation
|
lsocast is a high density load-bearing insulation with grades for both cryogenic and high temperature applications.
the material has compressive and tensile strength to allow it to act as a support or anchor.
its insulating properties ensure that the temperature at the interface with the supporting steelwork is as near to ambient as possible.
designed to measure the static tension in a hanger rod.
a very accurate device to enable setting of pipework supported by spring hangers, to retrospectively determine the load at a support position or to monitor the build up of load on ducts or other equipment in a heavily-laden coal ash environment.
|
|
comet's monitoring system enables the passive long-term monitoring of pipework systems.
the system comprises a series of strategically placed transducers integrated via a 'bus' system and monitored through various hardware elements by an ibm-compatible pc.
the system can be configured to measure load, displacement, temperature and pressure.
be it an audit trail of the commissioning phase or the planning of preventative maintenance, the comet dedicated monitoring system can provide the solution.
|
